UCF Series
Unit No.
Bearing No.
Housing No.
Shaft Dia
Boundary Dimensions(mm)
Bolt Size
Mass(Kg)
in.
mm
a
e
i
g
l
s
z
Bi
n
≈
UCF201-8
UC201-8
F204
1/2
　
86
63.5
15
11
25.4
12
33.3
31
12.7
3/8
0.7
UCF202-10
UC202-10
F204
5/8
　
86
63.5
15
11
25.4
12
33.3
31
12.7
3/8
0.7
UCF204
UC204
F204
　
20
86
63.5
15
11
25.4
12
33.3
31
12.7
M10
0.7
UCF204-12
UC204-12
F204
3/4
　
86
63.5
15
11
25.4
12
33.3
31
12.7
3/8
0.7
UCF205
UC205
F205
　
25
95
70
16
13
27
12
35.7
34
14.3
M10
0.8
UCF205-14
UC205-14
F205
7/8
　
95
70
16
13
27
12
35.7
34
14.3
3/8
0.8
UCF205-15
UC205-15
F205
15/16
　
95
70
16
13
27
12
35.7
34
14.3
3/8
0.8
UCF205-16
UC205-16
F205
1
　
95
70
16
13
27
12
35.7
34
14.3
3/8
0.8
UCF206
UC206
F206
　
30
108
83
18
13
31
12
40.2
38.1
15.9
M10
1
UCF206-17
UC206-17
F206
1-1/16
　
108
83
18
13
31
12
40.2
38.1
15.9
3/8
1
UCF206-18
UC206-18
F206
1-1/8
　
108
83
18
13
31
12
40.2
38.1
15.9
3/8
1
UCF206-19
UC206-19
F206
1-3/16
　
108
83
18
13
31
12
40.2
38.1
15.9
3/8
1
UCF206-20
UC206-20
F206
1-1/4
　
108
83
18
13
31
12
40.2
38.1
15.9
3/8
1
UCF207
UC207
F207
　
35
117
92
19
15
34
14
44.4
42.9
17.5
M12
1.4
UCF207-20
UC207-20
F207
1-1/4
　
117
92
19
15
34
14
44.4
42.9
17.5
7/16
1.4
UCF207-21
UC207-21
F207
1-5/16
　
117
92
19
15
34
14
44.4
42.9
17.5
7/16
1.4
UCF207-22
UC207-22
F207
1-3/8
　
117
92
19
15
34
14
44.4
42.9
17.5
7/16
1.4
UCF207-23
UC207-23
F207
1-7/16
　
117
92
19
15
34
14
44.4
42.9
17.5
7/16
1.4
UCF208
UC208
F208
　
40
130
102
21
15
36
16
51.2
49.2
19
M14
1.8
UCF208-24
UC208-24
F208
1-1/2
　
130
102
21
15
36
16
51.2
49.2
19
1/2
1.8
UCF208-25
UC208-25
F208
1-9/16
　
130
102
21
15
36
16
51.2
49.2
19
1/2
1.8
UCF209
UC209
F209
　
45
137
105
22
16
38
16
52.2
49.2
19
M14
2.2
UCF209-26
UC209-26
F209
1-5/8
　
137
105
22
16
38
16
52.2
49.2
19
1/2
2.2
UCF209-27
UC209-27
F209
1-11/16
　
137
105
22
16
38
16
52.2
49.2
19
1/2
2.2
UCF209-28
UC209-28
F209
1-3/4
　
137
105
22
16
38
16
52.2
49.2
19
1/2
2.2
UCF210
UC210
F210
　
50
143
111
22
16
40
16
54.6
51.6
19
M14
2.4
UCF210-30
UC210-30
F210
1-7/8
　
143
111
22
16
40
16
54.6
51.6
19
1/2
2.4
UCF210-31
UC210-31
F210
1-15/16
　
143
111
22
16
40
16
54.6
51.6
19
1/2
2.4
UCF210-32
UC210-32
F210
2
　
143
111
22
16
40
16
54.6
51.6
19
1/2
2.4
UCF211
UC211
F211
　
55
162
130
25
18
43
19
58.4
55.6
22.2
M16
3.6
UCF211-32
UC211-32
F211
2
　
162
130
25
18
43
19
58.4
55.6
22.2
5/8
3.6
UCF211-34
UC211-34
F211
2-1/8
　
162
130
25
18
43
19
58.4
55.6
22.2
5/8
3.6
UCF211-35
UC211-35
F211
2-3/16
　
162
130
25
18
43
19
58.4
55.6
22.2
5/8
3.6
UCF212
UC212
F212
　
60
175
143
29
18
48
19
68.7
65.1
25.4
M16
4.4
UCF212-36
UC212-36
F212
2-1/4
　
175
143
29
18
48
19
68.7
65.1
25.4
5/8
4.4
UCF212-38
UC212-38
F212
2-3/8
　
175
143
29
18
48
19
68.7
65.1
25.4
5/8
4.4
UCF212-39
UC212-39
F212
2-7/16
　
175
143
29
18
48
19
68.7
65.1
25.4
5/8
4.4
UCF213
UC213
F213
　
65
187
149
30
22
50
19
69.7
65.1
25.4
M16
5.5
UCF213-40
UC213-40
F213
2-1/2
　
187
149
30
22
50
19
69.7
65.1
25.4
5/8
5.5
UCF214
UC214
F214
　
70
193
152
31
22
54
19
75.4
74.6
30.2
M16
6.1
UCF214-43
UC214-43
F214
2-11/16
　
193
152
31
22
54
19
75.4
74.6
30.2
5/8
6.1
UCF214-44
UC214-44
F214
2-3/4
　
193
152
31
22
54
19
75.4
74.6
30.2
5/8
6.1
UCF215
UC215
F215
　
75
200
159
34
22
56
19
78.5
77.8
33.3
M16
6.9
UCF215-47
UC215-47
F215
2-15/16
　
200
159
34
22
56
19
78.5
77.8
33.3
5/8
6.9
UCF215-48
UC215-48
F215
3
　
200
159
34
22
56
19
78.5
77.8
33.3
5/8
6.9
