SQD Series
Bearing No.
Boundary dimensions(mm)
Mass
d
d1
d2
l1
l2
l3
L
S1
C
D
rs
α°
Kg
min
max
max
min
≈
≈
SQD5
5
M5
9
8
8
19
27.5
7
6
16
0.3
25
0.014
SQD6
6
M6
10
11
8.8
23.8
33.5
8
6.75
18
0.3
25
0.021
SQD8
8
M8
12
12
11.6
28.6
41
10
9
22
0.3
25
0.042
SQD10
10
M10×1.25
14
15
14.2
34.2
49
11
10.5
26
0.3
25
0.067
SQD12
12
M12×1.25
17
17
15.1
38.1
55.1
15
12
30
0.5
25
0.108
SQD14
14
M14×1.5
19
22
16.8
51.3
70.7
17
13.5
34
0.5
20
0.167
SQD16
16
M16×1.5
22
23
18
54.5
76.3
19
15
38
0.5
20
0.238
