SQZ...RS Series
Bearing No.
Boundary dimensions(mm)
Mass
d
d1
d2
l1
l2
L
L1
L2
L3
D1
D2
α°
Kg
min
min
max
max
min
max
max
≈
≈
SQZ5-RS
5
M5
9
8
11
46
24
4
12
9
11
15
0.025
SQZ6-RS
6
M6
10
11
12.2
55.2
28
5
15
10
13
15
0.041
SQZ8-RS
8
M8
12
12
16
65
32
5
16
12.5
16
15
0.075
SQZ10-RS
10
M10×1.25
14
15
19.5
74.5
35
6.5
18
15
19
15
0.12
SQZ12-RS
12
M12×1.25
17
17
21
84
40
6.5
20
17.5
22
15
0.18
SQZ14-RS
14
M14×1.5
19
22
23.5
103
45
8
25
20
25
11
0.27
SQZ16-RS
16
M16×1.5
22
23
25.5
112
50
8
27
22
27
11
0.36
SQZ18-RS
18
M18×1.5
23
25
31
130.5
58
10
32
25
31
11
0.54
SQZ20-RS
20
M20×1.5
27
25
29
133
63
10
38
27.5
34
7.5
0.57
SQZ22-RS
22
M22×1.5
27
26
33
145
70
12
43
30
37
7.5
0.76
