Bearing No.	Boundary dimensions(mm)											Mass
	d	B	dk	C1	d2	G	h	l1	l2	rs	α°	Kg
				max	max	(inch)		min	max	min	≈	≈
SAZJ4	4.83	7.92	11.1	5.94	15.88	10-32	31.75	19.05	39.7	0.3	10	0.014
SAZJ6	6.35	9.53	12.7	6.35	19.05	1/4-28	39.67	25.4	49.2	0.3	13.5	0.018
SAZJ7	7.94	11.1	15.88	7.92	22.23	5/16-24	47.63	31.75	58.72	0.3	11	0.032
SAZJ9	9.53	12.7	18.26	9.12	25.4	3/8-24	49.23	31.75	61.93	0.6	11	0.05
SAZJ11	11.11	14.27	20.62	10.31	28.58	7/16-20	53.98	34.93	68.28	0.6	10.5	0.068
SAZJ12	12.7	15.88	23.81	11.05	33.32	1/2-20	61.93	38.1	78.59	0.6	10	0.11
SAZJ15	15.88	19.05	28.58	12.29	38.1	5/8-18	66.68	41.28	85.73	0.6	13	0.16
SAZJ19	19.05	22.23	33.32	15.06	44.45	3/4-16	73.03	44.45	95.25	0.6	12	0.26
