SIZJ Series

Bearing No.
Boundary dimensions(mm)
Mass
d
B
dk
C1
d2
G
h1
l3
l4
l5
W
d3
d4
rs
α°
Kg
max
max
(inch)
min
max
max
max
max
min
≈
≈
SIZJ4
4.83
7.92
11.1
5.94
15.88
10-32
26.97
12.7
34.93
4.75
7.92
7.54
10.31
0.3
10
0.018
SIZJ6
6.35
9.53
12.7
6.35
19.05
1/4-28
33.32
15.88
42.85
4.75
9.53
9.15
11.91
0.3
13.5
0.023
SIZJ7
7.94
11.1
15.88
7.92
22.23
5/16-24
34.93
15.88
46.02
4.75
11.1
10.72
12.7
0.3
11
0.036
SIZJ9
9.53
12.7
18.26
9.12
25.4
3/8-24
41.28
19.05
53.98
6.35
14.27
13.89
17.45
0.6
11
0.059
SIZJ11
11.11
14.27
20.62
10.31
28.58
7/16-20
46.02
22.23
60.33
6.35
15.88
15.49
19.05
0.6
10.5
0.082
SIZJ12
12.7
15.88
23.81
11.5
33.32
1/2-20
53.98
25.4
70.64
6.35
19.05
18.67
22.23
0.6
10
0.132
SIZJ15
15.88
19.05
28.58
12.29
38.1
5/8-18
63.5
31.75
82.55
7.92
22.23
21.84
25.4
0.6
13
0.195
SIZJ19
19.05
22.23
33.32
15.06
44.45
3/4-16
73.03
34.93
95.25
7.92
25.4
25.02
28.58
0.6
12
0.295
