SAZP...S Series
Bearing No.
Boundary dimensions(mm)
Mass
d
B
dk
C1
d2
G
h
l1
l2
rs
α°
Kg
max
max
(inch)
min
max
min
≈
≈
SAZP4S
4.83
7.92
11.1
6.35
15.88
10-32
31.75
19.05
39.7
0.3
10
0.013
SAZP6S
6.35
9.53
12.7
7.14
19.05
1/4-28
39.67
25.4
49.2
0.3
13
0.022
SAZP7S
7.94
11.1
15.88
8.74
22.23
5/16-24
47.63
31.75
58.72
0.3
10
0.037
SAZP9S
9.53
12.7
18.26
10.31
25.4
3/8-24
49.23
31.75
61.93
0.6
9
0.055
SAZP11S
11.11
14.27
20.62
11.1
28.58
7/16-20
53.98
34.93
68.28
0.6
11
0.078
SAZP12S
12.7
15.88
23.81
12.7
33.32
1/2-20
61.93
38.1
78.59
0.6
9
0.012
SAZP15S
15.88
19.05
28.58
14.27
38.1
5/8-18
66.68
41.28
85.73
0.6
11
0.18
SAZP19S
19.05
22.23
33.32
17.45
44.45
3/4-16
73.03
44.45
95.25
0.6
10
0.29
SAZP25S
25.4
34.93
47.63
25.4
69.85
5/4-12
104.8
53.98
139.7
0.6
14
1.1
