SIZP...S Series
Bearing No.
Boundary dimensions(mm)
Mass
d
B
dk
C1
d2
G
h1
l3
l4
l5
W
d3
d4
rs
α°
Kg
max
max
(inch)
min
max
max
max
max
min
≈
≈
SIZP4S
4.83
7.92
11.1
6.35
15.88
10-32
26.97
14.27
34.93
4.75
7.92
7.54
10.31
0.3
10
0.015
SIZP6S
6.35
9.53
12.7
7.14
19.05
1/4-28
33.32
19.05
42.85
4.75
9.53
9.15
11.91
0.3
13
0.025
SIZP7S
7.94
11.1
15.88
8.74
22.23
5/16-24
34.93
19.05
46.02
4.75
11.1
10.72
12.7
0.3
10
0.036
SIZP9S
9.53
12.7
18.26
10.31
25.4
3/8-24
41.28
23.8
53.98
6.35
14.27
13.89
17.45
0.6
9
0.061
SIZP11S
11.11
14.27
20.62
11.1
28.58
7/16-20
46.02
26.97
60.33
6.35
15.88
15.49
19.05
0.6
11
0.081
SIZP12S
12.7
15.88
23.81
12.7
33.32
1/2-20
53.98
30.15
70.64
6.35
19.05
18.67
22.23
0.6
9
0.133
SIZP15S
15.88
19.05
28.58
14.27
38.1
5/8-18
63.5
38.1
82.55
7.92
22.23
21.84
25.4
0.6
11
0.19
SIZP19S
19.05
22.23
33.32
17.45
44.45
3/4-16
73.03
44.45
95.25
7.92
25.4
25.02
28.58
0.6
10
0.285
SIZP25S
25.4
34.93
47.63
25.4
69.85
5/4-12
104.78
53.98
139.7
11.1
38.1
37.72
44.45
0.6
14
1
