SA ...ES Series
Bearing No.
Boundary dimensions(mm)
Mass
d
B
dk
C1
d2
G
h
l1
l2
rs
α°
Kg
max
max
6g
min
max
min
≈
≈
SA15ES
15
12
22
10.5
40
M14
63
34
83
0.3
8
0.121
SA17ES
17
14
25
11.5
46
M16
69
36
92
0.3
10
0.172
SA20ES
20
16
29
13.5
53
M20×1.5
78
43
104.5
0.3
9
0.283
SA25ES
25
20
35.5
18
64
M24×2
94
53
126
0.6
7
0.504
SA30ES
30
22
40.7
20
73
M30×2
110
65
146.5
0.6
6
0.835
SA35ES
35
25
47
22
82
M36×3
140
82
181
0.6
6
1.41
SA40ES
40
28
53
24
92
M39×3
150
86
196
0.6
7
1.86
SA45ES
45
32
60
28
102
M42×3
163
92
214
0.6
7
2.57
SA50ES
50
35
66
31
112
M45×3
185
104
241
0.6
6
3.58
SA60ES
60
44
80
39
135
M52×3
210
115
277.5
1
6
5.73
SA70ES
70
49
92
43
160
M56×4
235
125
315
1
6
7.94
SA80ES
80
55
105
48
180
M64×4
270
140
360
1
6
12.064
