Bearing No.	Boundary dimensions					Basic load rating(kN)		Limiting speeds		Mass
	mm					Dynamic	Static	rpm		Kg
	d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	≈
NUP2304E	20	52	21	1.1	0.6	42	39	12,000	14,000	0.242
NUP2305E	25	62	24	1.1	1.1	57	56	9,700	11,000	0.386
NUP2306E	30	72	27	1.1	1.1	74.5	77.5	8,300	9,700	0.58
NUP2307E	35	80	31	1.5	1.1	99	109	7,200	8,500	0.78
NUP2308	40	90	33	1.5	1.5	82.5	88	7,000	8,200	0.951
NUP2308E	40	90	33	1.5	1.5	114	122	6,400	7,500	1.06
NUP2309	45	100	36	1.5	1.5	99	104	6,300	7,400	1.27
NUP2309E	45	100	36	1.5	1.5	137	153	5,700	6,800	1.41
NUP2310	50	110	40	2	2	121	131	5,700	6,700	1.7
NUP2310E	50	110	40	2	2	163	187	5,200	6,100	1.9
NUP2311	55	120	43	2	2	148	162	5,200	6,100	2.17
NUP2311E	55	120	43	2	2	201	233	4,700	5,600	2.37
NUP2312	60	130	46	2.1	2.1	169	188	4,800	5,700	2.71
NUP2312E	60	130	46	2.1	2.1	222	262	4,400	5,200	2.96
NUP2313	65	140	48	2.1	2.1	188	212	4,400	5,200	3.27
NUP2313E	65	140	48	2.1	2.1	248	287	4,100	4,800	3.48
NUP2314	70	150	51	2.1	2.1	223	262	4,100	4,800	3.98
NUP2314E	70	150	51	2.1	2.1	274	325	3,800	4,400	4.25
NUP2315	75	160	55	2.1	2.1	258	300	3,800	4,500	4.87
NUP2315E	75	160	55	2.1	2.1	330	395	3,500	4,100	5.25
NUP2316	80	170	58	2.1	2.1	274	330	3,600	4,200	5.79
NUP2316E	80	170	58	2.1	2.1	355	430	3,300	3,900	6.25
NUP2317	85	180	60	3	3	315	380	3,400	4,000	6.7
NUP2317E	85	180	60	3	3	395	485	3,100	3,700	7.16
NUP2318	90	190	64	3	3	325	395	3,200	3,800	7.95
NUP2318E	90	190	64	3	3	435	535	2,900	3,400	8.56
NUP2319	95	200	67	3	3	370	460	3,000	3,500	9.2
NUP2319E	95	200	67	3	3	460	585	2,700	3,200	9.8
NUP2320	100	215	73	3	3	410	505	2,900	3,400	11.7
NUP2320E	100	215	73	3	3	570	715	2,600	3,100	12.8
NUP2322	110	240	80	3	3	605	790	2,600	3,100	17.1
NUP2322E	110	240	80	3	3	675	880	2,400	2,800	19.4
NUP2324	120	260	86	3	3	710	920	2,400	2,800	21.5
NUP2324E	120	260	86	3	3	795	1,030	2,200	2,500	26.1
NUP2326	130	280	93	4	4	840	1,130	2,200	2,600	26.9
NUP2326E	130	280	93	4	4	920	1,230	2,000	2,300	30.9
NUP2328	140	300	102	4	4	920	1,250	2,000	2,300	33.8
NUP2328E	140	300	102	4	4	1,020	1,380	1,800	2,100	38.7
NUP2330	150	320	108	4	4	1,020	1,400	1,900	2,200	40.6
NUP2330E	150	320	108	4	4	1,160	1,600	1,700	2,000	47.2
